Belden Hirschmann Industries（Suzhou）Ltd.
IEO-M12XM-M12XM-xxM CC-Link IE TSN Category 5e 1000 Mbps Double-Ended Cord set.
CC-Link IE TSN Category 5e 1000 Mbps Double-Ended Cord set: Male straight X-coded black M12 standard to male straight X-coded black M12 standard, shielded, LLDPE black cable, 8 wires.
特長
- Cable Design: 4P CAT5e SF/UTP/ PE/OS/OBS/PE Outdoor LAN Cable
- CC-Link IE TSN Reference Number: NRT-IT-00039
- Conductor Material: Solid Bare Copper
- Insulation Material: Polyolefin
- No. of Cores/Pairs (cable): 4 pairs
- Shielding Type: Al-Mylar + Braid
- Shielding Material: Tinned Copper
- Outer Jacket Material: LLDPE
- Overall Diameter (mm): Nom. 6.80 mm
- Operational Temperature: -30°C to + 80°C
- Oil Resistance: Yes
- UV/Sunlight Resistance: Yes
- Maximum operating voltage (V): 300 V
- Characteristics Impedance (Ω @ 1-100MHz): 100 ± 15 Ω
- RoHS Compliant: Yes
- For Connector:
Connector Type: M12 Standard
Data Transmission: 1000 Mbit/s
Connector Pins: 8
Coding: X
Contact Resistance: ≤ 10 mOhm
Insulation Resistance: > 10ᶺ8 Ohm
Mating Cycles: ≤ 100
Protection Degree / IP Rating: IP65 & IP67
Contact plating: Cu/Au
Flammability class (Contact Bearer): UL 94 V-0
Flammability class (Moulded Body): UL 94 HB rated
Attachment Material: CuZn
Attachment Plating: Nickel-plated
Shielding Material: CuZn, tin-plated
Fastening Torque (Attachment): M12x1: 50-60 N-cm, hand-tight
| 局種別または製品の種類 | |
|---|---|
| 通信速度 | 1Gbps |
| 伝送可能距離 | |
| ケーブル外径/外形寸法 | |
| 質量 | |
| 標準価格 |
